200Ah 230Ah 280Ah 3.2V Grade A Lifepo4 Lithium Battery For Diy 12V 24V 48V
Product Details:
| Place of Origin: | China |
| Brand Name: | chargofine |
| Certification: | UN38.3 MSDS |
| Model Number: | 3.2v200Ah 230Ah 280Ah 320Ah |
Payment & Shipping Terms:
| Minimum Order Quantity: | 300 |
|---|---|
| Price: | $89-$115 |
| Packaging Details: | Normal |
| Delivery Time: | 5-10days |
| Payment Terms: | T/T, T/T |
| Supply Ability: | 20000/month |
|
Detail Information |
|||
| Brand: | EVE/CATL/BYD | Model Name: | 3.2V Lifepo4 Battery |
|---|---|---|---|
| Rechargeable: | YES | Capacity(mAh): | 200Ah 230Ah 280Ah 320Ah |
| Max Charge Current: | 1C | Max. Discharge Current: | 1C |
| Dimension And Weight: | Golf Trolley/carts, Power Tools...Solar And Wind Power System | ||
| High Light: | 200Ah Lifepo4 Lithium Battery,48V Lifepo4 Lithium Battery,Diy Lifepo4 Lithium Batteries |
||
Product Description
Shenzhen Grade A Lifepo4 200Ah 230Ah 280Ah 3.2V Lithium Battery Akku For Diy 12V 24V 48V Lifepo4 Lithium Batterie
Why us:
1. For Batteries LFP Prismatic cells , 2500+ cycles ,3 Years Warranty , Support 4S4P , Group24 size ,12KG.
2. For services 24- hours after sales line , one step services , give you entile solutions for your project.
3. For after sales Free mantenance , Free repair , Free replacement if can't repair during Warranty.
4. For customize needs we can customize for you , such Voltage , Capacity , discharge current etc.
5. For additional benefits For resellers we provide super price for you and policy, pls contact us if interest !
Model
| Battery | With | Voltage | Capacity | Max Charge Current | Max Dis. Current | AC IR. | Weight | Dimension |
| QR Code | (mm) | |||||||
| LF50K | Yes | 3.2V | 50Ah | 100A | 150A | ≤0.5mΩ | 1.5kg | H185*W135*T30 |
| LF80 | Yes | 3.2V | 80Ah | 80A | 240A | ≤0.5mΩ | 1.7KG | H170*W130*T36.7 |
| LF100 | Yes | 3.2V | 100Ah | 50A | 300A | ≤0.5mΩ | 2kg | H118.5*W160*T50 |
| LF105 | Yes | 3.2V | 105AH | 105A | 315A | ≤0.15mΩ | 2kg | H196*W130*37 |
| LF120 | Yes | 3.2V | 120Ah | 120Ah | 240A | ≤0.5mΩ | 2.84kg | H166*W174*T48 |
| LF160 | Yes | 3.2V | 160AH | 320A | 320A | ≤0.5mΩ | 3.0KG | H157*W174*T54 |
| LF202 | Yes | 3.2V | 202AH | 100A | 200A | ≤0.25mΩ | 4.06kg | H173*T54*H209.6 |
| LF230 | Yes | 3.2V | 230AH | 230A | 230A | ≤0.25mΩ | 4.2kg | H200*W173*T72 |
| LF280 | Yes | 3.2V | 280AH | 280A | 280A | ≤0.25mΩ | 5.3kg | H208*W173*T72 |
| LF304 | Yes | 3.2V | 304Ah | 300A | 300A | ≤0.25mΩ | 5.5KG | H200*W173*T72 |
| LF302 | Yes | 3.2V | 302Ah | 300A | 300A | ≤0.25mΩ | 5.4KG | H206*W175*T73 |
DIY assembled battery note
Professionals will detected voltage/resistance/appearance and other issues before every shipment, we can only ensure that the
single battery is good, when arrival you can test the cells within 15 days, after that means batteries have no problem, does not
provide return nor refund. If you found problems you can contact us for return or refund. Battery can only be unused (the
electrode intact, no welding, no wear, the appearance good) to provide return. Any return behavior buyers need to be responsible
for shipping fee.
Courier and logistics
In addition, because the battery is prohibited product, many courier and logistics are unable to send, the arrival will indeed be
slower, so please wait patiently after place an order. Can Not give us bad feedback due to the courier company or because of the
courier service slow or other factors. open dispute will be unacceptable. Sorry for any inconvenience.
Life: Excellent calendar and cycle life.
Applications:
Passenger and commercial battery electric vehicles (BEVs)
Solar power storage ,e-bike , e scooter, golf cart And Others .
wildly use battery, model aircraft, electric tools,power tools , Golf carts, sightseeing coaches,diy battery pack ,solar energy, inverters and others
